PWM Pro Charge Controller 12V/24V 30A USB

PWM 12/24-30 (MPN 1-01-010920) is a microprocessor-controlled solar charge controller with a maximum charging capacity of 30A and can charge both 12V and 24V batteries. It uses modern 3-stage PWM modulation to get the most out of your AGM, GEL, or lead-acid batteries. It is suitable for solar systems with a maximum PV output of 390W at 12V and 780W at 24V battery voltage.

During charging, important environmental parameters such as battery temperature (only with optional sensor) are used to calculate the optimal charging current. As soon as the battery voltage is in the full charge range, the charging voltage is gradually reduced. This prevents both gassing and heating of the batteries, thus maximizing their service life. Charging then continues at a reduced voltage until your batteries are actually “full.” The result of this mode of operation is better, faster charging without deteriorating the health of your battery.

Performance characteristics of the PWM-12/24-30
max. charging current 30A, for up to 390W PV power in 12V and 780W in 24V systems
for 12V systems, maximum PV voltage of 22V; for 24V systems, 50V
modern, 3-stage PWM charge control for gentle and efficient charging of your battery(ies)
3 battery types can be set: AGM, GEL, and liquid lead acid
intuitive operation via 2 buttons directly on the device
large LCD display with numerous display options, including kWh meter
2 USB ports with a maximum output of 2.4A
Load output with numerous configuration options, e.g., for lighting control
Temperature-compensated battery charging (optional temperature sensor required, not included)
Integrated device and battery protection
PV short-circuit protection – Automatic disconnection in the event of a short circuit on the solar side.
PV reverse polarity protection – Automatically interrupts the connection in the event of incorrect polarity on the solar side.
overload protection – If the maximum permissible load current at the controller is exceeded by 5%, the controller automatically disconnects the existing load.
Overheating protection – If the cooling body temperature in the controller rises above 85°, the device switches off automatically and switches back on again as soon as the temperature falls below 70°.
Protection against short circuits at the load output – Automatic interruption of the connection in the event of a short circuit at the load output.
